In C-Werk, each WS-216 video capture card corresponds to two devices: manufacturer Grundig, model TW5864 PCI (driver Yuan, 2) and manufacturer CaptureDevice, model CaptureDevice (driver DShow, 1).

Note

If you have a WS-216 card added through the Yuan driver, in Windows Server OS you should activate: Desktop Experience Feature.

Сameras connected to C-Werk through the WS-216 card require the following configuration: add Grundig TW5864 PCI device configuration (2) and select the checkbox Send settings to device (see The Camera object).

Note

C-Werk does not support receiving uncompressed video from WS-216 video capture cards.

For video cameras that are connected through WS-216 video capture cards, you can choose one of the two codecs for a video stream:

1. H.264 (configurable).

2. H.264 (minimum resolution, non-configurable).
